Higher switching frequencies, steeper filtering, and higher-tolerance components deliver sound above and beyond the expectation of Class D – in an amazingly compact package! AFC8., 14BIT | Audison 8-Channel X 100W RMS Power Amplifier with Built-in DSP Amplifier Tech Data Channels 8 Class D-Class Power supply voltage / fuse 11 ÷ 15 VDC / 1 x 35A Operating power supply voltage 6., 5 ÷ 17., 5 VDC Idling current 1., 3 A Standby Current Draw 1., 5 mA Consumption @ 14., 4 VDC, 2Ω, Max Musical Power 34 A Remote IN 4 ÷15 VDC (1 mA) Remote OUT 6., 5 ÷15 VDC (150 mA) ART - Automatic Remote Turn on/ off from OUTPUT BTL speakers 1., 5 VDC Efficiency Rated Power 81% Amplifier Stage Distortion - THD @ 1 kHz, 4Ω, 70% Rated Power 0., 05% Bandwidth @ -1., 5 dB 10 Hz ÷ 42 kHz Damping factor @ 1 kHz, 4Ω, 2 VRMS 85 S/N ratio (A weighted @ 1 V Input) Master Input 98., 5 dBA S/N ratio (A weighted @ 1 V Input) Optical Input 105 Total Power RMS 800 W Minimum load impedance 2Ω Output Continuous Power (RMS) @14., 4 VDC, 1% THD 8 Ch @ 4Ω: 65 W x 8 8 Ch @ 2Ω: 100 W x 8 4Ch (Bridge 1/2; 3/4; 5/6; 7/8) @ 4Ω: 200 W x 4 Adjustable Crossover Yes CEA Specifications Output power @ 4Ω, 1% THD+N, 14., 4 V 55 W x 8 SN ratio (ref. ) Digital IN 1 x Optical S/PDIF; Max 192 kHz / 24 bit + 1 x Optical/Coaxial S/PDIF with optional F2O card Input Optical IN 1 x Optical S/PDIF; Max 192 kHz / 24 bit + 1 x Optical/Coaxial S/PDIF with optional F2O card Digital Signal Processor Audio DSP Converter Analog Devices ADAU1467 automotive qualified audio processor processing @ 96 kHz. Audison Dsp Amplifier Remote Controller Amps For Sale Audison AFC8.14BIT 8-Channel X 100W RMS Power Amplifier With Built In Dsp 192260 High-fidelity Car Audio Product Description Audiophile Sound You Expect From Audison - AF C8.14 bit boasts eight high-fidelity amplified channels 65W x 8 @4*, 100W x 8 @2*, with the audiophile sound of the latest generation Audison D-Class technology This is combined with native DSP working at 24 bit/96 kHz, extending the audio band up to 40 kHz and earning the coveted High-Resolution certification. Support for the Audison B-CON’s Absolute Volume function guarantees maximum bit depth, even with wireless connections! New Audison APF8.9 BIT PRIMA Series 85W x 8 RMS @4Ohms 8-Channel Audison bit Drive update 1.2 software for car audio processor Audison bit Drive software for DSP features a brand new Graphical User Interface, a technician’s most powerful tool Bridging channel pairs results in 200W x 4 @4Ω*, guaranteeing flexible and powerful performance. *Output Continuous Power (RMS) @14., 4 VDC, 1% THD, all channels driven.
